Thông số kỹ thuật
| Range of product | Harmony XK |
|---|---|
| Product or component type | Complete joystick controller |
| Product specific application | Light hoisting applications |
| Device short name | XKBA1233CA |
|---|---|
| Bezel material | Metal |
| Fixing collar material | Metal |
| Sale per indivisible quantity | 1 |
| Protective treatment | TC |
| Ambient air temperature for storage | -40…70 °C |
| ambient air temperature for operation | -20…70 °C |
| Overvoltage category | Class I conforming to IEC 61140 |
| Standards | UL 508 EN/IEC 60947-5-1 CSA C22.2 No 14 |
| Operator position information | All positions |
| Operator profile | Handle with zero position mechanical interlock |
| Notch per direction | 1…3 notches at 0-12°-20°-28° for each direction |
| Mechanical durability | 1000000 cycles |
| Vibration resistance | 6 gn (f= 1…70 Hz) conforming to IEC 60068-2-6 |
| Shock resistance | 20 gn (duration = 11 ms) conforming to IEC 60068-2-27 |
| Connections - terminals | Captive screw clamp terminals, <= 2 x 1.5 mm² with cable end Captive screw clamp terminals, <= 1 x 2.5 mm² without cable end Captive screw clamp terminals, >= 1 x 0.5 mm² |
| Short-circuit protection | 10 A cartridge fuse type gG conforming to EN/IEC 60947-5-1 |
| [Ith] conventional free air thermal current | 10 A conforming to EN/IEC 60947-5-1 10 A conforming to CSA C22.2 No 14 10 A conforming to UL 508 |
| [Ui] rated insulation voltage | 500 V (pollution degree 3) conforming to IEC 60947-1 |
| Compatibility code | XKB |
