Rơ le quá dòng điện tử, EOCRSSD-30W Digital, 3A đến 30A, 380-440VAC
Specifications
| Range of product | EOCR |
|---|---|
| Device short name | EOCR-SSD |
| Product or component type | Protection relay |
| Protection type | Overload, In > OC setting Sensitivity to phase loss Locked rotor for starting, In > 2 times OC setting |
| Product specific application | Overcurrent protection |
| Network type | AC |
| Network frequency | 50...60 Hz |
| protection ajustment range | 3…30 A |
| Tripping threshold | 3...30 A |
| [Us] rated supply voltage | 380-440 V AC |
|---|---|
| Mounting support | 35 mm DIN rail Panel |
| Contacts type and composition | 1 NC + 1 NO (OL) |
| Short-circuit and overload protection | By 4 A gG fuse |
| [Ue] rated operational voltage | 600 V AC 50...60 Hz for power circuit conforming to UL 690 V AC 50...60 Hz for power circuit conforming to CSA 690 V AC 50...60 Hz for power circuit conforming to IEC 60947-4-1 |
| [Uimp] rated impulse withstand voltage | 6 kV conforming to IEC 60947-4-1 |
| Reset | Manual reset Electrical 0…1 s by interruption of power supply |
| Time delay type | D-Time: 1...30 s O-Time: 0.5, 1...10 s |
| Display type | 7 segments LED |
| power consumption per relay | 3 W |
| Connections - terminals | Control circuit: lug-clamp 2 x 1…2.5 mm²flexible without cable end - M3.5 Control circuit: cable 2 x 1…2.5 mm²flexible without cable end - M3.5 Control circuit: cable 2 x 1…2.5 mm²flexible with cable end - M3.5 |
| Tightening torque | Control circuit: 1.7 N.m on lug-clamp, cable, 7 mm |
| Height | 70 mm |
| Width | 56 mm |
| Depth | 77.2 mm |
| Net weight | 0.255 kg |
