Specification
| Measurable connector | RJ45 connector |
|---|---|
| Measurable cable | Twisted-pair cable(shielded wire(STP), unshielded wire(UTP)) |
| Measurable cable category | CAT5, CAT5e, CAT6, CAT6A |
| Wiremap function （Testable length range 100m or less） |
Opens, shorts, crossed, reversed, transposed, split pairs, and shielded / unshielded |
| Cable length measurement | 0.1 to 255m |
| Accuracy | ±10% ±1m |
| Operating temperature & humidity range | 0 to 40℃, relative humidity of 80% or less(no condensation) |
| Storage temperature & humidity range | -10 to 60℃, relative humidity of 70% or less(no condensation) |
| Applicable standard | IEC 61326-1(EMC) |
| Power source | R03 / LR03(AAA)(1.5V)×6 |
| Dimension | Display unit：156(L)×73(W)×35(D)mm Remote unit：72(L)×23(W)×24(D)mm |
| Weight |
Display unit：Approx.245g(including batteries) |
| Accessories |
8551-1(Remote unit (ID.1)) |
| Optional accessories | 8551-25(Remote units (ID.2 to 5)) 8551-68(Remote units (ID.6 to 8)) |
